YK-BP80005 Frequency converter
Product Model : YK-BP80005
Product Information :
Output capacity (VA):500VA Circuit mode:（IGBT）SPWM Pulse Width Modulation AC input:Single-phase 220VAC, 50Hz / 60Hz AC output Phase:Single-phase AC Output Voltage Low range:0~150V AC Output Voltage High range:150-300V AC Output Frequency:45Hz~70Hz adjustable 50HZ/ 60HZ can be optional AC Output Maximal current0~150V: 4.2A AC Output Maximal current 0~300V: 2.1A

Information

The ultrahigh precision Frequency converter / Frequency Conversion Power Supply series of the product YK-BP80005 adjustable frequency power source is widely used in many kinds of professional fields. Provide customers the systematic solution of power supply. the consideration of electric environment, optimization of load collocation, matching of power supply selection, design of conforming to requirements, excelsior and highly efficient manufacture, timely and perfect maintenance, etc., all of which of YK-BP80005 adjustable frequency power source can fully meet customers’ requirements.

Character

1. Programmable dynamic output voltage

2. High precision frequency stabilizing and voltage stabilizing, key-press quick

3. Adjustment voltage and frequency

4. High precision display: voltage, current, frequency and active power

5. Unique time setting function, control output time 0~16 hours adjustable

6. Unique voltage frequency group shortcut output mode 220V/50Hz, 110V/60Hz and 120V/60Hz

7. Output frequency: 47～63Hz(400Hz optional)

8. Output voltage: 0~300V can adjust and simulate voltages from all countries in the world

9. It has multiple protections of overvoltage, over current, overload, over temperature and alarm function

Application

For civil use, for industrial use, for military or aircraft use etc.

Customize Range

Regard as the frequency converter , we can customized different specification are as following

Ø 1phase/3phase input

Ø 1phase/3phase output

Ø 50hz, 60hz, 45-70hz, 400hz available.

Ø With 1-200KVA capacity.

For civil use, for industrial use, for military or aircraft use etc.

Model	Input voltage	Output voltage	AC Input frequency	AC output Phase voltage	Output frequency	Output capacity	Output adjust type
YK-BP81 Series	1phase/3 phase	1 phase	50/60hz	0-150V 0-300V	50/60hz, 45-70hz, 400hz option	0-200kva	Knob type
YK-BP80 Series	1phase/3 phase	1 phase	50/60hz	0-150v 151-300v	47-63hz 220v/50hz, 110v/60hz, 120v/60hz	0-200kva	Press key type
YK-BP83 Series	1phase/3 phase	3 phase	50/60hz	0-150V 0-300V	50/60hz, 45-70hz, 400hz option	0-600kva	Knob type
YK-BP88 Series	1phase/3 phase	1phase/3 phase	50/60hz	0-150V 0-300V	400hz for military or aircraft	0-600kva	Knob type

Specification

Model (YK-BP)			YK-BP80005
Output capacity (VA)			500VA
Circuit mode			（IGBT）SPWM Pulse Width Modulation
AC input			Single-phase 220VAC, 50Hz / 60Hz
AC output	Phase		Single-phase
	Voltage	Low range	0~150V
		High range	150-300V
	Frequency		45Hz~70Hz adjustable 50HZ/ 60HZ can be optional
	Maximal current	0~150V	4.2A
		0~300V	2.1A
Frequency stability rate			≤±0.1%
Load voltage stabilizing rate			≤±0.5%
Waveform			Sine wave
Waveform distortion degree			≤1.5%(resistance load)
Efficiency			More than 85%
Response time			≤2ms
Display and resolution		Digit frequency	4 digits display, resolution 0.1Hz
		Digit voltage	4 digits display, resolution 0.1V
		Digit current	4 digits display, resolution 0.01A
		Digit power	4 digits display, resolution 1W
		Digit power factor	4 digits display, resolution 0.001
Protection			overvoltage, over current, overload, over temperature and short-circuit, as well as automatic jump protection and alarm device
Cooling			Forced fan cooling
Working temperature			0℃~45℃, Relative 0～90%（ non- condense ）
Shape		Dimensions (mm)	300420190
		Net Weight(Kg)	24.0KG
		Gross weight	35.0KG
