1.Constant voltage design
5.Electrical appliances, industrial equipment, telecommunications and so on.
BUCK DC-DC CONVERTER MODEL LIST
Model Series |
Input-V |
Output-V |
Output Current |
YK-DD1224S5** |
12V/24V |
5V |
3A|5A|10A|15A|20A|30A|40A|50A|60A |
YK-DD24S12** |
24V |
12V |
1.5A|3A|5A|8A|10A|15A|20A|30A|40A|50A|60A|85A|100A |
YK-DD24S13.8** |
24V |
13.8V |
5A|10A|15A|20A|30A|40A|50A|60A |
YK-DD24S19** |
24V |
19V |
5A|10A|15A |
YK-DD36S12** |
36V |
12V |
5A|10A|15A|20A|30A|50A|60A |
YK-DD48S5** |
48V |
5V |
5A|10A|15A|20A |
YK-DD48S12** |
48V |
12V |
5A|10A|15A|20A|30A|50A|60A |
YK-DD48S13.8** |
48V |
13.8V |
5A|10A|15A|20A|30A|40A|50A|60A |
YK-DD48S19** |
48V |
19V |
5A|8A|10A |
YK-DD48S24** |
48V |
24V |
3A|5A|10A|15A|20A|30A|40A|50A |
YK-DD60S12** |
60V |
12V |
5A|10A|15A |
YK-DD60S24** |
60V |
24V |
5A|10A |
BOOST DC-DC CONVERTER MODEL LIST
Model Series |
Input-V |
Output-V |
Output Current |
YK-DD12S24** |
12V |
24V |
1A|2A|3A|5A|8A|10A|15A|20A|25A|30A|40A|50A |
YK-DD12S19** |
12V |
19V |
5A|8A|10A|15A|20A |
YK-DD12S28** |
12V |
28V |
3 A|5A|8A|10A|15A|20A|25A|30A|40A |
YK-DD12S36** |
12V |
36V |
1A|2A|3A|5A|6A|8A|10A|20A|30A|40A |
YK-DD12S48** |
12V |
48V |
1A|2A|3A|4A|8A|10A|15A|20A |
YK-DD24S48** |
24V |
48V |
3 A|5A|10A|20A|30A|40A |
YK-DD24S36** |
24V |
36V |
5A |
BUCK& BOOST DC-DC CONVERTER MODEL LIST
Model Series |
Input-V |
Output-V |
Output Current |
YK-DD12S12** |
8-40V |
12V |
1A|2A|3A|5A|6A|10A|15A|20A|25A |
YK-DD12S13.8** |
8-40V |
13.8V |
3A|5A|10A|15A|20A|25A |
YK-DD24S24** |
9-40V |
24V |
2A|3A|4A|6A|10A|15A |
ISOLATED BUCK DC-DC CONVERTER MODEL LIST
Model Series |
Input-V |
Output-V |
Output Current |
YK-DD48S12** |
35-100V |
12V |
8A|10A |
YK-DD48S5** |
36-75V |
5V |
15A|20A |
YK-DD48S24** |
36-75V |
24V |
5A |
AC-DC CONVERTER MODEL LIST
Model Series |
Input-V |
Output-V |
Output Current |
YK-ACD12S12** |
10-28V |
12V |
1A|2A|3A|5A|6A|8A|10A |
YK-ACD24S12** |
15-28V |
12V |
1A|2A|3A|5A|6A|8A|10A |
YK-ACD24S5** |
8-28V |
5V |
1A|2A|3A|5A|6A|8A|10A |
YK-ACD24S24** |
22-28V |
24V |
1A|2A|3A|5A|6A|8A|10A |
YK-ACD36S5** |
AC8-38V |
5V |
1A|2A|3A|5A|6A|8A|10A |
YK-ACD36S12** |
AC15-38V |
12V |
1A|2A|3A|5A|6A|8A|10A |
YK-ACD36S24** |
AC32-38V |
24V |
1A|2A|3A|5A|6A|8A|10A |
Model |
3 |
5 |
8 |
10 |
15 |
||
Input |
|||||||
Rate voltage |
12Vdc |
||||||
Input voltage |
10-14Vdc |
||||||
Output |
|||||||
Rate voltage |
15Vdc±0.25vdc |
||||||
Rate current |
3A |
5A |
8A |
10A |
15A |
||
Rate power |
45W |
75W |
120W |
150 |
225W |
||
Conversion efficiency |
>90% |
||||||
Voltage regulation |
±1% |
||||||
Load regulation |
± 2% |
||||||
Ripple (Full load test) |
< 150mV |
||||||
No-load current |
< 60mA |
||||||
Working temperature |
-20~80℃ |
||||||
Waterproof rating |
IP67 |
||||||
Protection |
Over-current / voltage / load protection |
||||||
Overheat protection |
|||||||
Lower voltage protection |
|||||||
Intrusion protection |
|||||||
Short-circuit protection and automatic recovery |
|||||||
Full waterproof potting |
|||||||
Dimension |
Small & thin plastic shell |
SIZE : 46*27*14mm |
NW: 30g |
||||
Middle plastic shell |
SIZE : 46*32*18mm |
NW: 50g |
|||||
Large plastic shell |
SIZE : 58*40*22mm |
NW: 97g |
|||||
Small aluminum shell |
SIZE : 43.5*24.5*20.5mm |
NW: 45g |
|||||
Large aluminum shell |
SIZE : 74*74*32mm |
NW: 250g |
|||||
Install cable |
13-15(cm) |
