12v 24v 25a intelligent fast lead acid battery charger for truck

25A Intelligent and fast battery charger with LCD Display
Product Model : YK-CD122425
Product Information :
1. Input Voltage：AC150v-250v, 50-60HZ 2. Output Voltage ：12V/24V 3. Output Current：25A 4. Suitable ：12V Battery（8-14.5V）24V Battery（18-29V） 5. Input mode: Pulse 6. Size:22.6*18.1*9.9cm cm, GW:2kg 7. Smart charging and repairing integrated charger 8. 12V 24V automatic identification 9. Intelligent charge and fast charge for opton 10. With Digital LED Display window show the charge voltage/Current

Information

1. Multi-function charger is widely used in 12v/24v battery, it can identify different kind of batteries in automatically
2. Multi-function charger Use the advanced pulse width modulation technology with three-stage battery charge in automatic function
3. Microcomputer power chip digital pulse restore to improving the battery life greatly.
4. With multiple protection.
5. Output short circuit protection & Overheating protect & Reverse connecting protection & Over current protection & Full charging automatic shutdown protection

Character

1. Intelligent charging and repairing integrated charger

2. 12V 24V automatic identification

3. Charge mode option : Intelligent charge and fast charge for switch

4. Multi protection : Short circuit protection/Reverse protection/Over-current protection/Overheating protection/Low voltage protection/Overvoltage protection

5. With Digital LED Display window show the charge voltage/Current

Application

1. Multi-function charger is widely used in 12v/24v battery, it can identify different kind of batteries in automatically
2. Application Field: Motorcycle /Vehicle /SUV/TRUCK

Customize Range

Regards Lead Acid Battery Charger, we can customize below model.
Such as:

12VDC 24VDC 10A
12VDC 24VDC 15A
12VDC 24VDC 25A

Specification

Model : YK-CD122425 Smart charging and repairing integrated charger
INPUT
Input Voltage	AC220V±15% (AC150V-250V)
Frequency	47-63hz
Work Efficiency	88%
Input mode	Pulse
OUTPUT
Output voltage	12Vdc 24Vdc , 12V 24V automatic identification
Output Current	25A
Suitable	12V Lead acid Battery（8-14.5V）; 24V Lead acid Battery（18-29V）
Intelligent charging mode	Automatically detect battery demand, current adjustable , battery be full stop power
Automatic charging mode	Manually check battery temperature, if temperature is too higher , charger stop charging
Multi protection	Short circuit protection/Reverse protection/Over-current protection/Overheating protection/Low voltage protection/Overvoltage protection
Display	With Digital LED Display window show the charge voltage/Current
WORK CONDITIONS
Operation temperature	-30℃ - +50℃
Operation humidity	5% to 95% RH Non-condensing
Fan noise	≤55Db
Max Altitude	10000m
Dimension & Weight
Dimension	22.618.19.9cm
Weight	2kg
